Machining

Design: Portal design
Turning table:stationary/moveable
Crossrail: stationary/moveable
Swing diameter [mm]: 2,000 - 4,500
Turning height [mm]: 1,000 - 3,000
Rotary table drive power [kW]: 63 - 200
Weight of workpiece [t]: 12 - 25

Design: Portal design
Crossrail: Fixed
Diameter of workpiece [mm]: 200 - 650
Length of workpiece max. [mm]: 4,700
Grinding length max. [mm]: 3,500
Power of grinding support [kW]: 55 / 75

Design: Portal design
Turning table:stationary/moveable
Crossrail: Fixed/moveable
Swing diameter [mm]: 3,000 - 6,000
Turning height [mm]: 1,000 - 5,000
Rotary table drive power [kW]: 100 - 200
Weight of workpiece [t]: 80

Design: Reciprocating-table type.Machine portal equipped with 2 or 3 grinding supports
Crossrail: Fixed
Power of grinding support [kW]: 35
Setup length [mm]: 4,000 - 8,000 (can be expanded as needed)

Design: Portal design
Crossrail: stationary/moveable
Clearance width [mm]: 1,000 - 3,500
Power of grinding support [kW]: 22 / 50
Clearance height [mm]:1,000 - 3,500
Setup length [mm]: 2,000 - 15,000

Power [kW]: 63/80
Clearance width [mm]: 2,000 - 6,000
Clearance height [mm]: 1,500 - 5,500
Setup length [mm]: > 2,000

Design: Portal design
Turning table:stationary/moveable
Crossrail: Fixed/moveable
Swing diameter [mm]: 5,000 - 14,000
Turning height [mm]:3,000 - 12,000
Rotary table drive power [kW]: 100 - 300
Weight of workpiece [t]: 200 - 400

Power [kW]: 80 / 105 / 130
Clearance width [mm]: 3,500 - 14,000
Clearance height [mm]: 2,000 - 10,000
Setup length [mm]: > 4,000 - 50,000

Milling Ram [kW]: 45
Length of workpiece [mm]: 3.000 - 50.000
Width of workpiece [mm]: 2.500 - 6.000
Clearance height [mm]: 1.000 - 2.500
Acceleration [m/sec²]: 3

Power [kW]: 45 / 63
Clearance width [mm]: 2,000 - 4,500
Clearance height [mm]: 1,500 - 4,000
Setup length [mm]: >2,000
