WALDRICH COBURG Vertical Turning machines

In 1997 WALDRICH COBURG expanded their product range with vertical turning machines and are continuously developing them. WALDRICH COBURG also produce combined machines with milling and turning supports.

Particularly when demanding requirements are placed on complex technologies, accuracy, machining efficiency, workpiece dimensions and productivity, our customers can rely on us.

Sort by

WALDRICH COBURG ValuTurn

ValuTurn

Design: Portal design
Turning table:stationary/moveable
Crossrail: stationary/moveable
Swing diameter [mm]: 2,000 - 4,500
Turning height [mm]: 1,000 - 3,000
Rotary table drive power [kW]: 63 - 200
Weight of workpiece [t]: 12 - 25

WALDRICH COBURG MultiTurn

MultiTurn

Design: Portal design
Turning table:stationary/moveable
Crossrail: Fixed/moveable
Swing diameter [mm]: 3,000 - 6,000
Turning height [mm]: 1,000 - 5,000
Rotary table drive power [kW]: 100 - 200
Weight of workpiece [t]: 80

WALDRICH COBURG PowerTurn

PowerTurn

Design: Portal design
Turning table:stationary/moveable
Crossrail: Fixed/moveable
Swing diameter [mm]: 5,000 - 14,000
Turning height [mm]:3,000 - 12,000
Rotary table drive power [kW]: 100 - 300
Weight of workpiece [t]: 200 - 400
